Human step-up approval for agent actions: CIBA

Some actions should never ride on a token an agent already holds. Issuerd implements Client-Initiated Backchannel Authentication (CIBA, poll mode) so an agent can escalate a single action to the human behind it: the user sees an explicit approval request with a binding message, and only an approval mints a short-lived, DPoP-bound step-up token carrying the privileged scope.

• Why agents need step-up
• Issuerd’s CIBA at a glance
• The step-up pattern
• Walkthrough
• Recorded demo
• Limits and notes
• Source map

Why agents need step-up

Least privilege is not only about what a token can do — it is about when the authority exists at all. An autonomous agent that can list orders should not permanently hold the power to refund them. The healthy shape is:

• The everyday login token carries no privileged scope. refunds:execute exists nowhere in the agent’s standing credentials.
• When a task crosses a policy line the agent itself defined (“refunds above $100 need a human”), the agent asks the identity provider to interrupt the user.
• The user approves or denies, with the action spelled out in a binding message they actually read — not a generic consent screen.
• Only then does a token carrying refunds:execute come into existence: a short lifetime (the realm’s access-token lifespan, 300 s by default), bound to the agent’s DPoP key, usable for exactly the approved action.

This is CIBA’s consumption-device/authorization-device split applied to agents: the agent is the consumption device, the user’s browser session is the authorization device, and the binding message is the contract between them.

Issuerd’s CIBA at a glance

Backchannel authentication endpoint	POST /realms/{realm}/protocol/openid-connect/ext/ciba/auth (advertised in discovery as backchannel_authentication_endpoint)
User approval endpoint	POST /realms/{realm}/protocol/openid-connect/ext/ciba/approve (browser form POST under the user’s SSO session)
Token polling	grant_type=urn:openid:params:grant-type:ciba with auth_req_id at the realm token endpoint
Delivery modes	poll only; ping and push are out of scope

Authentication request parameters (parsed in crates/issuerd-protocol/src/ciba.rs):

Parameter	Semantics
scope	Optional; when present, every scope must be assigned to the client (default or optional), otherwise invalid_scope — a client cannot pick up authority the admin never granted it
login_hint / login_hint_token / id_token_hint	At least one required, identifying the user to interrupt. User resolution currently honors login_hint (the username) only — a request carrying just one of the other hints parses but then fails with 400 unknown_user_id
binding_message	Up to 100 characters; shown to the user at approval time and echoed in the flow — “Refund $150 for order #123”, not “Approve request”
requested_expiry	Overrides the default 120 s lifetime of the pending request
acr_values, user_code, client_notification_token	Parsed per the spec (the notification token matters for ping/push, which are not implemented)

Polling semantics, per the spec:

• A pending request answers authorization_pending; polling faster than the advertised interval (default 5 s) answers slow_down; user denial answers access_denied.
• Only the client that initiated the request may poll it (CIBA §7.1) — another client presenting the auth_req_id is rejected.
• A disabled client cannot start backchannel authentication at all.

DPoP threading. When the polling request carries a DPoP proof, the issued step-up token is bound to that proof key (cnf.jkt) — the same binding discipline as every other grant. The privileged token is sender-constrained for its entire (short) lifetime. From there it feeds straight into the RFC 8693 exchange: step-up token in, aud = mcp-server, scope = "refunds:execute" token out, still DPoP-bound.

The step-up pattern

The configuration that makes the story hold together:

1. Assign the privileged scope (refunds:execute) to the agent’s client as an optional scope — and never request it at ordinary login. The login token then provably lacks it.
2. Assign the same scope to the downstream resource’s client (e.g. mcp-server) so a step-up token can be exchanged into that audience.
3. Encode the autonomy policy in the agent (“refunds above $100 need approval”), and encode the enforcement in the resource server (refund_order requires refunds:execute or answers 403 insufficient_scope). The agent’s policy is a convenience; the resource’s check is the guarantee.
4. Use a binding message that names the action, amount, and target. The user approves a specific decision, not a category.

Walkthrough

# 1. The agent starts backchannel authentication (client-authenticated).
curl -u app8-chat:<secret> -X POST \
  https://idp.example.com/realms/myrealm/protocol/openid-connect/ext/ciba/auth \
  -d scope="openid refunds:execute" \
  -d login_hint=alice \
  -d binding_message="Refund $150 for order #123"
# → {"auth_req_id":"f1b56bd6-…","expires_in":120,"interval":5}

# 2. Alice's browser (SSO session cookie) approves or denies:
curl -b "issuerd_session_<realm>=…" -X POST \
  https://idp.example.com/realms/myrealm/protocol/openid-connect/ext/ciba/approve \
  -d auth_req_id=f1b56bd6-… -d action=approve

# 3. The agent polls with a DPoP proof until approval lands.
curl -u app8-chat:<secret> -X POST \
  https://idp.example.com/realms/myrealm/protocol/openid-connect/token \
  -H "DPoP: <proof for POST .../token>" \
  -d grant_type=urn:openid:params:grant-type:ciba \
  -d auth_req_id=f1b56bd6-…
# pending → {"error":"authorization_pending"}
# approved → access_token: scope="openid refunds:execute", cnf.jkt=<proof key>, expires_in=300  # realm access-token lifespan
# denied  → {"error":"access_denied"}

# 4. Exchange the step-up token into the MCP audience (see agentic-iam-mcp.md)
#    and call refund_order with it. When the token expires, the authority is gone.

Recorded demo

The full loop — a refund request that exceeds the agent’s autonomous limit, the in-app approval card backed by a real CIBA flow, the DPoP-bound step-up token, and the same call without step-up dying with a real 403 — recorded against a live Issuerd lab rig:

1. “Refund $150 for order #123” — over the agent’s $100 autonomous limit, so it starts CIBA with binding_message = "Refund $150 for order #123", scope = "openid refunds:execute" (trace shows auth_req_id, expires_in: 120, interval: 5).
2. Approval — the user clicks Approve on the in-app card; the approval rides the existing SSO session. The next poll returns a step-up token: scope = "openid refunds:execute", DPoP-bound, with the realm’s access-token lifespan as TTL (300 s by default).
3. Refund executed — the agent exchanges the step-up token into aud = mcp-server and the MCP server applies the refund; order #123 flips to refunded.
4. The control — a bare curl calling refund_order with the ordinary (non-step-up) token: HTTP/1.1 403, error="insufficient_scope", scope="refunds:execute". No human said yes, so no such authority exists.

Limits and notes

• Poll mode only. CIBA ping and push delivery are deliberately out of scope (see Project Scope in the README); client_notification_token is parsed but no outbound notification is attempted.
• Pending requests live in the distributed cache (ciba:{auth_req_id}) with their expiry as TTL — they work across a cluster and disappear on their own. An unknown or expired auth_req_id answers expired_token at both the approval and polling endpoints.
• The approval endpoint is a browser form POST under the realm SSO session; it is same-site by design (the session cookie is SameSite=Lax), which is what allows in-app approval cards on sibling subdomains without any CORS surface.
• Every CIBA decision is auditable through the realm’s login events (recorded by default): ciba_auth when a backchannel request is accepted (details carry the scope, expiry, and the binding message’s length — never the message text, which can carry PII), ciba_auth_error for rejections (invalid_scope, disabled or unknown client, missing hint, unknown/expired auth_req_id at approval, cross-user approval attempts), ciba_approve / ciba_deny for the user’s decision, and a login event with details.method=ciba when a poll mints the tokens. A denied or expired poll records login_error with access_denied / expired_token; authorization_pending and slow_down polls are protocol chatter and record nothing.

Source map

Component	Path
Request parsing and validation	crates/issuerd-protocol/src/ciba.rs
Backchannel auth + approval handlers	crates/issuerd-server/src/routes/oidc.rs (ciba_auth_handler, ciba_approve_handler)
Polling in the token endpoint	crates/issuerd-server/src/routes/oidc.rs (urn:openid:params:grant-type:ciba)
DPoP binding of the issued token	crates/issuerd-server/src/dpop.rs
Discovery advertisement	crates/issuerd-protocol/src/discovery.rs (backchannel_authentication_endpoint)
